Tpo Waterproofing
TPO waterproofing is a type of membrane designed to prevent water from penetrating into structures such as tunnels, foundations, and roofs. It is made primarily from thermoplastic olefin sheets, combined with a self-adhesive and a surface anti-stick protective layer. The overlap area is isolated using isolation materials where necessary, and the TPO membrane is bonded to the concrete by means of pre-laying. The edges of the overlap are welded together using hot air without the need for additional layers or protection layers. The material itself is relatively soft, making it easy to work with during corner construction, resulting in lower levels of leakage and seepage. Due to its properties, TPO waterproofing is a popular choice for tunnel waterproofing projects.
- Fast Delievery
- Quality Assurance
- 24/7 Customer Service
Product Introduction
Specification
| Product Name | Type | Thickness | Roll size |
| TPO waterproof membrane 60 mil | homogeneous, reinforced adhesive, fiber back | 1.2mm-2.0mm 60 mil-1.5mm 40mil-1.2mm |
1-2m width 20-30m length or customer made |
TPO waterproofing coil benefits:
-
Super weather resistance: TPO waterproof coils are resistant to aging, deformation, damage, and other phenomena brought on by changes in the external environment, ensuring that the waterproof effect is long-lasting and effective. They can withstand tests from the natural environment and human factors, such as oxidation, ultraviolet light, high temperatures, low temperatures, strong winds, and heavy rain.
-
Super tensile strength: The TPO waterproof coil has a tensile strength of over 10MPa, which is significantly higher than that of other waterproof coil kinds. Its exceptional durability, bearing capacity, and stability can be confirmed by testing it under demanding conditions of deformation, distortion, stress, and load.
A type of membrane called TPO waterproofing is intended to stop water from leaking into buildings including roofs, foundations, and tunnels. Its main components are sheets of thermoplastic olefin, which are also covered with a surface anti-stick protective layer and self-adhesive. When necessary, isolation materials are used to isolate the overlap area, and pre-laying is used to attach the TPO membrane to the concrete. Hot air is used to fuse the overlapped edges together without the need for further layers or protective layers. Because of the material's relative softness, which makes it easy to work with when building corners, seepage and leakage are reduced. TPO waterproofing is a common option for tunnel waterproofing projects because of its characteristics.
TPO waterproofing has several benefits over conventional waterproofing techniques in addition to being more successful at stopping water intrusion. The self-adhesive quality adds stability and ease of installation, negating the need for extra adhesives to provide a strong bond. By offering protection from debris, scratches, and punctures, the anti-stick protective layer further increases the membrane's longevity. Using TPO waterproofing guarantees a dependable, long-lasting waterproofing solution that needs little upkeep over time.
Because TPO waterproofing is 100% recyclable and can be manufactured from recycled components, its environmental effect is reduced, making it a sustainable and environmentally beneficial material. It is perfect for outdoor application because it is resistant to UV radiation, chemicals, and weathering. Its flexibility and low weight make it the perfect option for retrofitting projects that require the replacement of old waterproofing methods while simultaneously lowering the total weight of the construction.
To sum up, TPO waterproofing is a cost-effective, useful, and long-lasting solution for waterproofing requirements. Its distinct qualities, simplicity of installation, remarkable durability, and low maintenance needs make it a widely sought-after choice for a broad range of building projects. You can minimize environmental effect and guarantee the long-term success of your project by investing in TPO waterproofing.
Super self-adhesive: TPO waterproof coils can be made extremely self-adhesive through a unique process and formula. This eliminates the need for extra adhesives, welding supplies, and protective layers during construction, lowering the cost and difficulty of the process while also enhancing safety and effectiveness.
Extreme environmental protection: TPO waterproof coils are made using non-toxic, odorless, solvent-free, and pollution-free raw ingredients and production processes that comply with international environmental norms and laws and are safe for both the environment and human health.
technology data sheet
| 1 |
Tensile strength |
maximum tension, N/cm |
Longitudina |
≥250 |
360 |
|
Transverse |
310 |
||||
|
Elongation % |
Longitudina |
≥15 |
18 |
||
|
Transverse |
22 |
||||
|
2 |
Dimension variance rate (heat treatment) % |
Longitudina |
≤0.5 |
0.15 |
|
|
Transverse |
≤0.5 |
0.1 |
|||
|
3 |
Bending at low temperature |
- |
-40℃, no leakage |
Pass |
|
|
4 |
Water Impermeability |
- |
0.3Mpa, 2h, impervious |
Pass |
|
|
5 |
Shock resistance |
- |
0.5kg·m, no leakage |
Pass |
|
|
6 |
Peel strength of jointing |
N/mm |
≥3.0 |
6.3 |
|
|
7 |
Static Load Resistance |
- |
20kg no leakage |
Pass |
|
|
8 |
Trapezoid tearing strength N |
Longitudinal |
N |
≥450 |
655 |
|
Transverse |
N |
525 |
|||
|
9 |
Water absorption (70℃, 168h) |
% |
≤4.0 |
2.2 |
|
FAQ
1. Why choose us?
We have more than 20+ years exporting experience and production technology, Strict quality control system with good quality and competitive price, OEM service. Our products has exported to more than 30 countries, Obtain the recognition of multinational customers.
2. Sample and quality
The free samples will be provided in 3days.
3. What is your payment term?
T/T advance or L/C at sight.
