TPO Rv Roof Membrane
TPO rv roof membrane, a sheet thermoplastic rubber elastic waterproof material,is made from vinyl resin, using advanced technology and specific formua.It is called the world's top waterproof material.
- Fast Delievery
- Quality Assurance
- 24/7 Customer Service
Product Introduction
Product Description
This TPO Rv Roof Membrane is a sheet thermoplastic rubber elastic waterproof material. It is made of vinyl resin, using advanced technology and specific formula for precise molding. As a widely praised material, the product is widely used in planting roofs, underground, dams, landfills, subways, tunnels, bridges, airports, grain depots, large venues, etc., with a service life of 20-25 years. We will pack your products in plastic bags or woven bags to ensure safe transportation. Please store the product in a cool and ventilated place. We have been rooted in this industry for many years, so we have conducted a good research on the production and use of waterproof products. If you have any questions, please contact us.
Features
1. It has excellent long-term weather resistance, UV resistance, heat resistance and aging resistance.
2. It has high mechanical strength, excellent physical performance, stable size and color.
3. It has long term plasticity and recyclability.
4. It has high reflectivity, high UV resistance, high energy conservation and high cold resistance.
5. The joint is welded by hot air, which is firm, reliable and has long-term welding capacity.
Specification
Product Name | Type | Thickness | Roll size |
TPO Rv Roof Membrane | homogeneous, reinforced adhesive, fiber back | 1.0mm-2.0mm | 1-2m width |
Data Sheet
1 | Tensile strength | maximum tension, N/cm | Longitudina | ≥250 | 355 |
Transverse | 305 | ||||
Elongation % | Longitudina | ≥15 | 18 | ||
Transverse | 21 | ||||
2 | Dimension variance rate (heat treatment) % | Longitudina | ≤0.5 | 0.3 | |
Transverse | ≤0.5 | 0.1 | |||
3 | Bending at low temperature | - | -40℃, no leakage | -40℃, no leakage | |
4 | Water Impermeability | - | 0.3Mpa, 2h, impervious | 0.3Mpa, 2h, impervious | |
5 | Shock resistance | - | 0.5kg·m, no leakage | 0.5kg·m, no leakage | |
6 | Peel strength of jointing | N/mm | ≥3.0 | 6.4 | |
7 | Static Load Resistance | - | 20kg no leakage | 20kg no leakage | |
8 | Trapezoid tearing strength N | Longitudinal | N | ≥450 | 644 |
Transverse | N | 516 | |||
9 | Water absorption (70℃, 168h) | % | ≤4.0 | 2.2 | |
Thickness | Roll Size | Rolls/ Pallet | Pallets/ 20' Container |
1.2 mm | 15 m2 | 25 | 20FCL |
20 m2 | 25 | ||
30 m2 | 25 | ||
1.5 mm | 15 m2 | 25 | |
20 m2 | 25 | ||
30 m2 | 23 |
Why choose us?
- We offer a range of accessories and components to complement our TPO Waterproof Membrane products.
- Our company has been committed to providing professional services for customers, providing high-quality TPO Rv Roof Membrane and technical services is our purpose.
- Our TPO Waterproof Membrane is compatible with a range of insulation materials for added energy-efficiency.
- All our products are designed and manufactured in strict accordance with relevant national standards, and are widely used in various industries due to their excellent performance.
- We have a dedicated R&D team that continuously improves our products.
- To improve production efficiency, quality and stable and durable performance as the criterion to win customer satisfaction and recognition.
- We have years of experience in the industry and have established a reputation for excellence.
- To provide customers with high quality service is the direction of our work and the yardstick of value evaluation.
- Our TPO Waterproof Membrane has excellent dimensional stability and can resist expansion and contraction.
- Our company has passed the certification of quality management system, environmental management system and occupational health and safety management system, and obtained the certification of TPO Rv Roof Membrane production plant exported to the United States.
