Products

Foundation Membrane

Fountains are a stunning addition to any landscape, but their beauty is not complete without proper waterproofing. One important component of fountain waterproofing is the foundation membrane, which serves as a vital barrier between the water feature and the structure upon which it sits. In this article, we will discuss the characteristics and advantages of the asphalt self-adhesive waterproofing membrane and how it can be used effectively on fountains.

Send Inquiry

Fast Delievery
Quality Assurance
24/7 Customer Service

Product Introduction

Product Description

Product Features

The most significant benefit of foundation membrane is its water-resistant nature, which is achieved by the use of bitumen. The asphalt layer at the base of the membrane makes it extremely durable, flexible, and able to withstand underground and weather-related stresses. At the same time, the protective coating applied to the outer layer of the membrane shields it from the effects of UV radiation.

Specification

Product Name	Type	Thickness	Roll size
Self adhesive foundation membrane	Strong cross film, aluminum film, hdpe film	1.2mm-2.0mm	1m width 20-30m length or customer made

Data Sheet

Product Name			Self adhesive foundation membrane
1	Elongation at Break	Longitudinal	N/50mm	≥150	382
		Lateral	N/50mm	≥150	365
		Longitudinal Max	%	≥30	650
		Lateral Max	%	≥30	715
2	Tear Strength	Longitudinal	N	≥12	53
2	Tear Strength	Lateral	N	≥12	53
3	Flexibility at Low Temperature		℃	-15℃, no cracks	Pass
4	Water Impermeability		-	0.3MPa, 120min, Impervious	Pass
5	Heat resistance		-	70℃, 2h, no flow	Pass
6	Peel strength (membrane to membrane)		N/mm	≥1.0	2.10

Advantages of Foundation Membrane

The advantages of using foundation membrane are numerous and widely recognized throughout the industry. The waterproofing properties of asphalt self-adhesive membrane make it the most popular choice for below-grade applications. Additionally, the ease of installation is a significant advantage, since it does not involve hot asphalt or open flames.

Foundation Membrane Installation for Fountains

When it comes to installing foundation membrane on fountains, it is essential to choose a perfect option that will offer an excellent waterproofing solution. Below is a general guide on how to install foundation membrane on fountains:

Step 1: Select the Correct Membrane Thickness - Depending on the height and complexity of the fountain, it is essential to select the appropriate thickness of the foundation membrane for the particular application.

Step 2: Clean Surface - Thoroughly clean the fountain's foundation surface, ensuring that all dirt, debris, and loose materials are removed. Any remaining coating or membrane should be removed. This should leave a clean, smooth surface, free of imperfection.

Step 3: Measure and Cut Foundation Membrane - Measure the foundation surface and cut the foundation membrane to fit perfectly. Carefully apply the membrane to the surface, using a roller to flatten, and press it in place.

Step 4: Seam Sealing - Use full or strips of membrane to seal any membrane joints and prevent water from penetrating underneath the membrane.

Step 5: Cover with Concrete - Once the foundation membrane has been installed, the fountain should be filled with concrete to form the basis of the fountain.

In conclusion, foundation membrane is an essential component of fountain waterproofing. It provides excellent protection against water and other environmental stressors that could damage the fountain. Thus, for those looking to preserve the beauty of their fountains, foundation membrane is an excellent addition.
